MG-X equipped with a high-heat-resistant quartz tube A high-heat-resistant quartz tube is used for the light-emitting part. It is designed to withstand continuous light emission at full power, so you can concentrate on shooting without missing the shutter timing.

Fast charge with lithium-ion batteries in as little as about 1.5 seconds.



Name of Main components_en.png



Above information is a test result record, it may be affected by equipment and environmental factors.

(*) Those functions depend upon the camera model, available in compatible cameras only.

Design and Specifications are subject to change without prior notice.

Firmware update

Before update

To start the firmware update procedure, you need to have:
• The computer (Windows or Mac) connected to the Internet
• USB OTG Type-C flash drive under FAT32 format (recommend 32GB)
• 4pcs of full charged Li-ion / re-chargable AA batteries.

Update procedure

1. Download the firmware file.
2. Connect USB flash drive to the computer.
3. Format it to FAT32 format (backup before format).
4. Copy firmware file to USB flash drive.
5. Eject it.
6. Insert fully charged batteries into MG-X.
7. Insert the USB flash drive into the MG-X.
9. Switch on the MG-X.
    The pilot light of MG-X will blink in yellow.
10. The green light will emit when the firmware update procedure
     completed. Switch off and remove the USB flash drive.
11. Switch on the MG-X.


How to check firmware version

1. Switch off power.
2. Hold the Pilot and Power button.
3. LCD display will show firmware versions.
4. Release the Pilot and Power button,
    firmware version page will disappear and returns to the main page.


License Agreement

Nissin end-user license agreement

By downloading firmware software of Nissin Digital Ltd. ("Nissin" ) from this site, you agree to the following terms and conditions. If you do not agree with such terms and conditions do not download the software. The terms of an end-user license agreement accompanying a particular firmware file upon installation or download of the firmware shall supersede the terms presented below.

The firmware is designed for use on Nissin product. Except as set forth below, such firmware is licensed to you subject to the terms and conditions of the end-user license agreement from Nissin governing your use of the firmware on Nissin product.

Disclaimer of warranties: you agree that Nissin has made no express warranties to you regarding the firmware and that the firmware is being provided to you "as is" without warranty of any kind. Nissin disclaims all warranties with regard to the software, express or implied, including, without limitation, any implied warranties of fitness for a particular purpose, merchantability, merchantable quality, or noninfringement of third-party rights.

Limit of liability: In no event will Nissin be liable to you for any loss of use, interruption of business, or any direct, indirect, special, incidental, or consequential damages of any kind (including lost profits) regardless of the form of action whether in contract, tort (including negligence), strict product liability or otherwise, even if Nissin has been advised of the possibility of such damages.

You shall not, or shall not have any third party, reverse-engineer, decompile, or disassemble this firmware.

I have read and understood the disclaimer above and wish to download the designated software

The latest version

001        12-2022
